Image Sensor VOx Uncooled Focal Plane Arrays
Max. Resolution 256 × 192
Frame Rate 50 Hz
Pixel Interval 12 μm
Response Waveband 8 μm to 14 μm
NETD Less than 20 mK (@25°C), F#=1.0
Lens (Focal Length) 9.7 mm, F1.0
Focus Mode Focus Free
Min. Focusing Distance 3.4 m
Magnification 1.4 × - 11.2 × (8 ×)
Field of View(H × V), Degrees
/ m @100 m
18.0° × 13.6°/31.7 m × 23.8m
Detection Range 500 m
Image Display
Display 1024 × 768, 0.39 inch, AMOLED
Contrast Adjustment Yes
Brightness Adjustment Yes
Palettes Black Hot, White Hot, Red Hot, Fusion, Red Monochrome, Green Monochrome
Exit Pupil 6 mm
Eye Relief 20 mm
Diopter (Range) -5 D to +3 D
Tone Adjustment Cold, warm
Zoom Pro Yes
HSIS (HIKMICRO Shutterless
Image System)
Yes
Image Pro 3.0 Yes
Sync Pro Yes
System
Storage Built-in EMMC (64GB)
Record Video Yes
Capture Snapshot Yes
Local Album Yes
Standby Mode Yes
PIP Yes
Hotspot 2.4/5 G WiFi Waveband
Hot Track Yes
Distance Measurement Yes
Audio Recording Yes
Power Supply
Battery Type Replaceable and rechargeable 18650 battery
Battery Operating Time TBD
Type-C Power Supply
5 V DC, 2 A
Supports External Power Supply, Support Direct Charging
General
Work Temperature/Humidity From -30°C to 45°C (-22°F to 113°F); Humidity: 90% or Less
Protection Level IP67
Dimension TBD
Weight TBD
